Rubber Compensator DN125 PN16 EPDM T90C Construction Length 130mm Flanged End Face Fully Sealed

Henan Lianghe Pipeline Equipment Co.,Ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap Rubber Compensator DN125 PN16 EPDM T90C Construction Length 130mm Flanged End Face Fully Sealed from wholesalers

    Buy cheap Rubber Compensator DN125 PN16 EPDM T90C Construction Length 130mm Flanged End Face Fully Sealed from wholesalers
    • Buy cheap Rubber Compensator DN125 PN16 EPDM T90C Construction Length 130mm Flanged End Face Fully Sealed from wholesalers
    • Buy cheap Rubber Compensator DN125 PN16 EPDM T90C Construction Length 130mm Flanged End Face Fully Sealed from wholesalers
    • Buy cheap Rubber Compensator DN125 PN16 EPDM T90C Construction Length 130mm Flanged End Face Fully Sealed from wholesalers

    Rubber Compensator DN125 PN16 EPDM T90C Construction Length 130mm Flanged End Face Fully Sealed

    Ask Lasest Price
    Brand Name : Liang He
    Model Number : KDF
    Certification : ISO 9001
    Price : $34.7-96.4 per set
    Payment Terms : T/T, D/A, D/P, Western Union, MoneyGram, L/C
    Supply Ability : 6000 piece per month
    Delivery Time : 1-7 day
    • Product Details
    • Company Profile

    Rubber Compensator DN125 PN16 EPDM T90C Construction Length 130mm Flanged End Face Fully Sealed

    Rubber compensator DN125 PN16 EPDM T90C Construction length 130mm flanged end face fully sealed


    Product Introduction

    End face fully sealed rubber connection is an improved product. It has the advantages of high pressure resistance, good elasticity, large displacement, anti-aging, vibration and noise reduction. It can also withstand high pressure, and its inner rubber layer extends to the outer edge of the flange, so as to realize the contact between the end face of the ball and the flange, which not only increases the high pressure resistance of the product, but also plays a good anti-pull-off role.


    Product Advantages

    The design of the end face fully sealed rubber joints gives them significant advantages in terms of installation and maintenance. Due to its small size and light weight, it is more convenient to install and maintain, and can easily adapt to different installation environments, reducing installation time and procedures. In addition, the simple structure of the end face fully sealed rubber joints makes it easy to disassemble and replace, reducing system downtime


    Product performance characteristics

    End face fully sealed rubber joints perform well in terms of performance. It can adapt to the lateral, axial and angular displacement of the pipeline, and is not limited by the non-concentric and non-parallel flanges of the pipeline, effectively absorbing the displacement, vibration and noise in the pipeline system, and ensuring the tightness and stability of the pipeline.

    Its high temperature resistance, acid and alkali resistance, and oil resistance make the end face fully sealed rubber joint still maintain performance in a variety of harsh environments and prolong the service life.


    Product parameters

    Nominal diameter

    Length

    (mm)


    Axial displacement

    (mm)


    Lateral displacement

    (mm)



    Deflection angle

    mminchElongationCompression
    321 1/49569915°
    401 1/295610915°
    5021057101015°
    652 1/21157131115°
    8031358151215°
    100415010191315°
    125516512191315°
    150618012201415°
    200821016252215°
    2501023016252215°
    3001224516252215°
    3501425516252215°
    4001625516252215°
    4501825516252215°
    5002025516252215°
    6002426016252215°
    7002826016252215°
    8003226016252215°
    9003626016252215°
    10004026018262415°
    12004826018262415°

    Tips:The above data is only part of the data, if you need a special size, please contact us.


    Product Installation

    1. Clean the pipe port: Make sure the surface of the pipe port is clean and free of foreign objects.
    2. Positioning the joint: Place the e
    nd face fully sealed rubber joint on the pipe port position that needs to be connected. Once you have determined the position, use a suitable tool (usually a wrench or screwdriver) to tighten the joint bolts or clamping screws to ensure that the joints are securely installed on both sides of the pipe.
    3. Keep the joint balanced: During the connection process, pay attention to ensure that the position of the joint is balanced between the two ends of the pipe.
    4. Check the connection: Make sure the joint is installed firmly and there is no looseness or misalignment.


    Product inspection and maintenance

    1. Check whether the rubber joint has cracks, aging, wear and tear, etc., and replace it in time.
    2. Check whether the bolt is loose, and if so, it should be tightened in time.
    3. Check whether there is any leakage in the flange, and deal with it in time if so.
    4. Wash the rubber joints regularly to keep them clean and prevent the accumulation of dust and dirt.


    Rubber Compensator DN125 PN16 EPDM T90C Construction Length 130mm Flanged End Face Fully Sealed


    Product packaging

    Rubber Compensator DN125 PN16 EPDM T90C Construction Length 130mm Flanged End Face Fully Sealed


    FAQ


    Q: Have your products been exported?

    A: Yes, they have been exported to USA, France, Australia, Peru, Chile, Brazil, Uruguay, Russia, UAE, Saudi Arabia, Oman, Egypt, Keyna, Serbia, Vietnam, South Korea, Indonisia, India, Thailand, Pakistan, Philippines, Singapore, HK...


    Q: What is your payment terms?

    A: Usually T/T(30% as deposit, the rest 70% will be paid before delivery), L/C, Western Union, Paypal also acceptable.


    Q: What are the diameters of end face fully sealed rubber joints?

    A: DN32-DN3000.


    Q: What is the operating temperature range of your products?

    A: -15℃ - +80℃(the special -20℃ — 150℃)


    Q: What are the functional characteristics of end face fully sealed rubber joints?

    A: Small size, light weight, easy installation and maintenance.
